Magewell USB Capture AIO

Magewell Capture Utility allows users to adjust desired settings for recordings (e.g. resolution, frame rate, color settings, and more).

The device features BNC SDI, DVI-I, and DB-9 VGA inputs, which are widely used in industrial, security, and medical applications. The DVI interface, in particular, has gained popularity in the medical and security industries due to its reliability.

This device offers an optimal solution for recording or streaming video with embedded audio and is also compatible with various platforms such as Zoom Rooms, Microsoft Teams Rooms, Skype for Business, Google Hangouts, GoToMeeting, VLC, OBS Studio, XSplit, etc.

Video & Audio Inputs

DVI-I + Audio:
- Connect to HDMI 2048x1080 60fps (via breakout cable) with HDMI embedded audio up to 8-channel 24-bit at 192kHz or analog audio.
- Connection to VGA + audio (via DVI-to-VGA connector)
- Connection to component + audio (via breakout cable)

BNC:
- Connection to SD/HD/3G-SDI 2048x1080 60fps with SDI embedded audio up to 8 channels or analog audio

DB9:
- Connection to YC (S-Video)

- Connection to composite video

- Connection to analog audio (L+R)

- Connection to component video


Video & Audio Outputs:
- Record videos up to 2048x2160 120fps and output audio with up to 2-channel audio streams for HDMI and SDI.

Input Interface:
- SDI x1
- DB9 x1
- DVI x1
- Support input resolution up to 2048×2160 pixels

Host Interface:
- USB 3.0

Video Engine:
- 8-bit video processing
- Deinterlace
- Cut
- Color adjustments
- Color field conversion
- Up/Down conversion
- Adjusting the aspect ratio
- Mirror & Rotate

Signal & Support:
- automatic detection of the input signal format
- 3D HDMI

Software:
- compatible with Windows, Linux, Mac, Chrome, OS
- Driverless use possible, firmware updates available
- USB Capture Utility & Capture Express incl.
