Magewell Ultra Encode SDI Plus

Sale price€653,90

Tax included.


The Ultra Encode SDI Plus encodes up to 4K at 30fps via the unit's 6G-SDI input. This model supports multiple video encoding formats and technologies—including H.264, H.265 (HEVC), NDI HX2, and NDI HX3—as well as a wide range of streaming protocols, including RTMP, RTMPS, SRT, RTSP, RTP, HLS, and TVU's ISSP technology.
In stock

Magewell Ultra Encode SDI Plus

- Live streaming and recording with support for H.264, H.265, NDI® HX2 and NDI® HX3

- Flexible selection of streaming protocols including RTMP, RTMPS, SRT, HLS and more

- Control via web interface or optional central management software Control Hub

Technische Details

Input features:
- Support for input signals up to 4096x2160 30fps and loopthrough
- Input and loop-through of embedded 16-channel SDI audio
- Audio input via 3.5 mm LINE IN

Coding features:
- Dual-stream encoding profiles: main stream and substream up to 4096x2160p30
- Maximum bitrate: 62Mbps (NDI® HX3), 32Mbps (others)
- Support for H.264/HEVC video encoding
- Video aspect ratio conversion, image rotation and cropping for the main and sub-stream
- 8-channel AAC encoding and audio channel allocation
- Side-by-side 3D video encoding

Streaming features:
- Natural support from Facebook, Twitch, YouTube and WOWZA
- Supported streaming protocols: RTSP/RTMP/RTMPS/SRT Caller/SRT Listener/NDI® HX2/NDI® HX3/HLS/TS over UDP/TS over RTP/TVU ISSP
- Allows 6 simultaneous sessions across multiple streaming protocols
- Streaming schedule support

Recording functions:
- Recording to internal storage (128 GB), external USB storage or network-attached storage (NFS/CIFS)
- Automatic upload of recorded files to a remote file storage platform
- Video recordings in MP4, MOV or TS format
-Normal recording and loop recording are supported
- Support for recording schedule

Miscellaneous:
- PoE available
- Tally lights for NDI® HX3
- Control via intuitive web GUI or HTTP APIs
- Provision of HTTP APIs
