Magewell Ultra Encode SDI e
Magewell

Magewell Ultra Encode SDI e

Sale price€546,90

Tax included.

The Magewell Ultra Encode SDI supports high-quality H.264 and H.265 (HEVC) encoding. Stream Full HD videos simultaneously to Facebook, YouTube, Twitch, and other streaming platforms. This device also supports other streaming protocols such as SRT, NDI|HX, HLS, RTMP, and RTMPS with wired or wireless network connectivity. SDI input supports input signals up to 2048x1080 60fps and loop-through signals.
In stock

Magewell Ultra Encode SDI e

Ultra Encode can be combined with our Pro Convert decoders to create flexible AV-over-IP infrastructures leveraging NDI®|HX and SRT technology. The devices can be configured and controlled via an intuitive web GUI or HTTP-based APIs, providing system integrators with exceptional deployment and integration flexibility.

A flexible and affordable universal encoder:
- Live H.264/H.265 streaming
- Supports streaming protocols such as SRT, NDI|HX, HLS & more
- Suitable for various network environments

Technische Details

Special features:
- Support for input signals up to 2048x1080 60fps and loopthrough signals
- Input and loop-through of embedded 16-channel SDI audio
- Audio input via 3.5 mm LINE IN

Coding features:
- Dual-stream encoding: main stream (maximum bit rate: 16 Mbps) and substream (maximum bit rate: 2 Mbps)
- Support for H.264/HEVC video encoding
- Encoding of 2-channel AAC at 48 kHz, 16 bit

Streaming features
- Supported streaming protocols: RTSP/RTMP/RTMPS/SRT Caller/SRT Listener/NDI|HX2/HLS (push)/TS over UDP/TS over RTP
- Enables streaming to multiple destinations simultaneously (selected protocols)

Others:
- Internet connectivity via wired Ethernet and wireless network
- Control via intuitive web GUI or HTTP APIs
