Magewell Ultra Encode HDMI e

Sale price€546,90

Tax included.


The Magewell Ultra Encode HDMI supports high-quality H.264 and H.265 (HEVC) encoding. Stream Full HD videos simultaneously to Facebook, YouTube, Twitch, and other streaming platforms. This device also supports other streaming protocols such as SRT, NDI|HX, HLS, RTMP, and RTMPS with wired or wireless network connectivity.
In stock

Magewell Ultra Encode HDMI e

HDMI input support for up to 4096x2160 4:4:4/4:2:2 30fps or 4096x2160 4:2:0 60fps input signals and loop-through signals.

Ultra Encode can be combined with our Pro Convert decoders to create flexible AV-over-IP infrastructures leveraging NDI®|HX and SRT technology. The devices can be configured and controlled via an intuitive web GUI or HTTP-based APIs, providing system integrators with exceptional deployment and integration flexibility.

A flexible and affordable universal encoder:
- Live H.264/H.265 streaming
- Supports streaming protocols such as SRT, NDI|HX, HLS & more
- Suitable for various network environments

Technische Details

Input Features:
- Support for up to 4096x2160 4:4:4/4:2:2 30fps or 4096x2160 4:2:0 60fps input and loop through signals
- Support for 48KHz, 16-bit 8-channel audio streams
- Input audio from 3.5mm LINE IN

Encoding Features:
- Dual stream encoding profiles: main stream (Max bitrate: 16Mbps) and sub stream (Max bitrate: 2Mbps)
- Support for H.264/HEVC video encoding
- Encoding 2-channel AAC at 48kHz, 16-bit

Streaming Features:
- Natively support streaming to Facebook, Twitch and YouTube
- Supported streaming protocols: RTSP/RTMP/RTMPS/SRT Caller/SRT Listener/NDI|HX2/HLS (push)/TS over UDP/TS over RTP
- Allow streaming to multiple destinations simultaneously (select protocols)

Other:
- Internet connectivity via wired Ethernet and wireless network
- Control via intuitive Web GUI or HTTP APIs
